Bridge power in hot climates, under ~100 MW
Gas engine gensets: modular, easy N+1, hold output in heat.
Equipment / Power generation
02 / POWER GENERATION
Power generation: gas engines and gas turbines
On-site generation for data centres: bridge, prime and backup power. Outputs are manufacturer ratings; site output is lower in heat and at altitude.
| Brand | Model | Output per unit | Frequency | Speed | Notes | Source |
|---|---|---|---|---|---|---|
| Caterpillar | G3520 Fast Response | 2.6 MW (50 Hz) | 50/60 Hz | — | 10 s start to load | ↗ |
| Caterpillar | CG260-16 | 4.0–4.5 MW | 50/60 Hz | — | Continuous rating | ↗ |
| INNIO Jenbacher | J420 | up to 1.56 MW | 50/60 Hz | — | — | ↗ |
| INNIO Jenbacher | J620 | 3.5 MW | 50/60 Hz | — | — | ↗ |
| INNIO Jenbacher | J624 | up to 4.5 MW | 50/60 Hz | — | — | ↗ |
| INNIO Jenbacher | J920 FleXtra | 10.6 MW (50 Hz) / 9.5 MW (60 Hz) | 50/60 Hz | — | — | ↗ |
| Wärtsilä | 20V34SG | 9.8 MW (50 Hz) / 9.4 MW (60 Hz) | 50/60 Hz | 750 / 720 rpm | Medium speed | ↗ |
| Wärtsilä | 31SG | 11.4–12.8 MW | 50/60 Hz | 750 / 720 rpm | — | ↗ |
| Wärtsilä | 18V50SG | 18.4 MW (50 Hz) / 18.9 MW (60 Hz) | 50/60 Hz | 500 / 514 rpm | — | ↗ |
| MAN Energy Solutions | 20V35/44G | 12.8 MW (50 Hz) / 12.3 MW (60 Hz) | 50/60 Hz | 750 / 720 rpm | — | ↗ |
| MWM | TCG 3020 V20 | 2.3 MW | 50/60 Hz | 1,500 rpm (50 Hz) | — | ↗ |
| Rolls-Royce mtu | Series 4000 gas | 1.0–2.5 MW | 50/60 Hz | — | 8V to 20V | ↗ |
Which one do I need?
Fast-start or mobile power
Aeroderivatives and trailer units: TM2500, SGT-A45 TR, FT8 MOBILEPAC.
Mid-size data centre campuses (20-60 MW)
Industrial turbines: Solar, SGT-400/600/800, Kawasaki L30A.
Heavy-duty frame: 7HA class.
What we need from you
Site frequency (50/60 Hz), MW needed and redundancy (N+1), design ambient temperature and altitude, fuel and gas pressure, grid-connected or island mode, target date.
We source new, surplus zero-hour and refurbished units. Every unit is verified by serial number with the OEM, and buyers arrange independent inspection.
Submit a requirement
